JW-KOFO Open Frame Diesel Generator 100kw 120kw 150kw 50/60hz Frequency 1500rpm/1800rpm Speed

Name: JWKOFO Open Frame Diesel Generator 100kw 120kw 150kw 5060hz Frequency 1500rpm1800rpm Speed
Brand: JIWEI
Price: 1 USD

China JW-KOFO Open Frame Diesel Generator 100kw 120kw 150kw 50/60hz Frequency 1500rpm/1800rpm Speed wholesale

Brand Name : JIWEI

Model Number : JW-KOFO

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiabce

Payment Terms : T/T

Delivery Time : 30work days

Packaging Details : Wooden box or plastic-sealed packaging

Rated Voltage : 230V,380V, 400V,440V

Rated Current : 200A-300A

Speed : 1500RPM, 1800RPM

Frequency : 50/60hz

Starting system : 24V DC Electric Start

Type : Container Type, Open Frame, Mobile Type

Cooling System Type : Water Cooling System

Warranty : Other

Rated power : 100kw 120kw 150kw

Engine : KOFO

Product name : JW-KOFO Open Frame Diesel Generator 100kw 120kw 150kw 50/60hz Frequency 1500rpm/1800rpm Speed

Generator : Stanford, Marathon, Leroy Somer, Grui Generator, etc

Contact Now

JW-KOFO Open Frame Diesel Generator 100kw 120kw 150kw 50/60hz Frequency 1500rpm/1800rpm Speed

overview

Product Advantages

Superior Performance

All-Copper Brushless Generator: Provides excellent conductivity and low loss.
Efficient Operation: Low fuel consumption and high thermal efficiency ensure long-lasting power and reduced operating costs.

Wide Range of Applications

Versatile Usage: Suitable as a backup or emergency power source for mines, railways, construction sites, and more.
Diverse Power Needs: Meets the requirements of factories, hospitals, hotels, schools, and other locations.

Ease of Use and Maintenance

Elegant Design: Features rainproof and anti-corrosion capabilities, allowing outdoor use without a dedicated machine room.
User-Friendly Access: Convenient access for adding fuel and battery; includes an emergency stop button for easy operation.

Reliable Product Quality

High-Quality Components: Constructed from reputable sources, ensuring durability.
Warranty Support: Backed by a two-year national warranty for after-sales service.

Comprehensive Service System

Expert Support: An experienced team ready to provide prompt assistance.
Standardized Processes: Stable pricing and lifetime cost maintenance for wear parts and damages.

Parameter list

Diesel generator set model	JW-60	JW-88
Generator set standby power (KVA)	69	110
Generator set standby power (KW)	55	88
Rated power of generator set (KVA)	63	100
Rated power of generator set (KW)	50	80
Rated current (A)	90	144
Unit reference weight (KG)	825	965
Unit reference dimensions (mm)	1900 * 615 * 1000	2100 * 675 * 1222
Engine model	4MN42-60D	4MT55-88D
Intake method	Pressurization	Pressurization
Burning method	Direct spray	Direct spray
Cylinder count	4	4
Bore × stroke (mm)	105 x 120	110 x 140
Displacement (L)	4.15	5.32
Compression ratio	17:1	17:1
Main power (kW)	60	88
Rotational speed (r/min)	1500/1800	1500/1800
Maximum idle speed (r/min)	1575 or less	1575 or less
Minimum no-load stable speed (r/min)	650 or less	650 or less
Fuel consumption rate (g/kW.h)	220 or less	225 or less
Crankshaft rotation direction (facing the flywheel)	Counterclockwise	Counterclockwise
Cooling methods	Forced water cooling	Forced water cooling
Lubrication method	Pressure splash compound	Pressure splash compound
Start method	Electric start	Electric start
Net mass (kg)	370	480
Cylinder working sequence	The 1-3-4-2	The 1-3-4-2
Exhaust temperature ℃	600 or less	600 or less
Intake pipe diameter mm	51	60
Total oil capacity L	13	15
Maximum oil temperature ℃	105	105
Oil consumption g/kW.h	2.04 or less	1.63 or less
Total cooling water capacity L	18	23
Dimensions (including water tank, air filter bracket, excluding air filter and muffler) mm	1075 * 630 * 938	1230 * 675 * 1022
Generator technical data:	Generator technical data:	Generator technical data:
Generator brand	JIWEI	JIWEI
Generator model	JW-FDJ50	JW-FDJ80
Generator rated power (KVA)	63	100
Generator rated power (KW)	50	80
Excitation mode	Brushless excitation	Brushless excitation
Frequency (HZ)	50/60	50/60
Power factor	0.8 Lag	0.8 Lag
Voltage (V)	380/415	380/415
Control system	SmartGen	SmartGen

We have cooperation with worldwide famous brands. For more specification,please contact us.

Our Advantages

JW-KOFO Open Frame Diesel Generator 100kw 120kw 150kw 50/60hz Frequency 1500rpm/1800rpm Speed

Our OEM Partners

are from different brands. With our customized solutions consistently delivering satisfaction ,we have won an esteemed reputation.

FAQ

1.Q: What is your MOQ of this item?
A:1 Sets.

2.Q: What is the lead time?
A:7 working days after received the 30%T/T deposit.
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others.
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month.
7.Q:What's the warranty time of diesel generators?
A:12 months or 1000 working hours, whichever comes first.

Why choose Jiwei to buy a generator set:

First, environmental protection and fuel saving: The advantages of gasoline generator include: optimized performance, ‌ flexible control, ‌ reduce NOx emission, ‌ high precision control, low vibration, low noise, low maintenance cost; ‌

Second,Delivery Guarantee: 1.fast delivery time: 1-5 days after receiving the deposit, except for special models; 2.Jiwei Company has been established for 20 years, with rich pre-sales and after-sales service capabilities, strong supply capabilities, stable supplier resources and rich logistics resources;

Third, strict quality inspection and testing procedures: 1,.each generator set has to go through a comprehensive test program, including 50% load, 75% load, 100% load, 110% load and all control and alarm, safety shutdown function inspection and certification. Fourth, service guarantee 1.provide free technical support, drawing design; 2.warranty time :2 years or 2000 hours to the first arrival (delivery starts to calculate the time); 3.service response time: within 30 minutes (telephone response); 4.spare parts supply: common repair, maintenance spare parts supply (shipped in China); 5.warranty address: global warranty;

Fifth,Customized Services: can be more customized products and LOGO according to your needs;

Sixth,Confidentiality we can sign quality assurance and confidentiality agreements with you, so that our cooperation is more stable;
